CST高分辨率大面阵工业相机
| 型号 | 分辨率 | 帧率(fps) | 感光芯片 | 靶面 | 像元(um^2) | 曝光方式 | 黑白/彩色 | 数据接口 | 相机尺寸 |
| CST-CG123-9GM/C | 4096×3000 | 9 | IMX304 | 1.1" | 3.45×3.45 | Global | M/C | GigE,POE | 29×44×58 |
| CST-CG250-4GM/C | 5120×5120 | 4 | GMAX0505 | 1.1" | 2.5×2.5 | Global | M/C | GigE,POE | 29×44×58 |
| CST-CG300-3GM/C | 6464×4852 | 3.6 | IMX342 | 22.3×16.7mm | 3.45×3.45 | Global | M/C | GigE | 72×72×64 |
| CST-CG654-1GM/C | 9344×7000 | 1.7 | GMAX3265 | 29.9×22.4mm | 3.2×3.2 | Global | M/C | GigE | 72×72×65 |
| CST-CG123-30UM/G | 4096×3000 | 23 | IMX304 | 1.1" | 3.45×3.45 | Global | M/C | USB 3.0 | 29×44×58 |
| CST-CG250-14UM/C | 5120×5120 | 14 | GMAX0505 | 1.1" | 2.5×2.5 | Global | M/C | USB 3.0 | 29×44×58 |
| CST-CG123-20CM/C | 4096×3000 | 20 | IMX304 | 1.1" | 3.45×3.45 | Global | M/C | CameraLink | 29×29×43.8 |
| CST-CG250-30CM | 5120×5120 | 30 | GMAX0505 | 1.1" | 2.5×2.5 | Global | M | CameraLink | 29×44×58 |
